Water Hose

Water Hose Product Detailed Specifications

1. Size Range

• Inner diameter: 3/16 inch to 8 inch (5mm to 200mm)

• Standard lengths: 20m, 30m, 50m, or custom bulk rolls

2. Working Pressure Capabilities

• Low pressure (water suction/delivery): Up to 300 psi

• Medium pressure: 300 psi – 1000 psi

• High Pressure Hose (wire reinforced): Up to 6000 psi

3. Pressure Performance

• Working pressure range: 150 psi to 6000 psi depending on reinforcement

• Burst pressure: 4:1 safety factor (minimum)

• Proof test pressure: 2x working pressure for 60 seconds

4. Performance Options

• Abrasion-resistant cover (up to 10x standard)

• Low-temperature flexibility (-40°C to -55°C)

• High-temperature resistance (up to +120°C continuous)

• Ultra-flexible designs for tight bending radius applications

5. Standard Compliance & Specification

• SAE 100R1, SAE 100R2 (Wire Braided Hose)

• SAE 100R12, SAE 100R13 (Wire Spiral Hose)

• EN 853, EN 856, EN 857

• ISO 1436, ISO 3862, ISO 18752

• China GB/T 3683, GB/T 10544

6. Impulse Performance

• Minimum 200,000 impulse cycles at 100°C

• Zero leakage or failure during dynamic pressure testing

7. Fluid Compatibility

• Excellent for water, air, mild chemicals, water-glycol fluids

• Resistant to ozone, UV radiation, and weathering

8. Flexibility & Bend Radius

• Minimum bend radius: 10x to 15x hose OD (depending on construction)

• Maintains flow area under pressure (no kinking)

9. Durability

• Abrasion resistance: Exceeds SAE J2000 requirements

• Corrosion-resistant reinforcement (zinc-plated or stainless steel wire)

• Weatherproof cover for 5+ years outdoor exposure

10. Temperature Range

• Continuous service: -40°C to +100°C (-40°F to +212°F)

• Intermittent: Up to +120°C (250°F) for steam/water mixtures

11. Structure & Materials (Technical Deep Dive)

Inner Tube Layer

• Material: EPDM (ethylene propylene diene monomer), NBR, or PVC

• Properties: Excellent water resistance, smooth bore for minimal friction loss, non-toxic options for potable water

• Hardness: 70±5 Shore A

Reinforcement Layer (Critical for Pressure Rating)

• Wire Braided Hose: 1 or 2 layers of high-tensile steel wire braided at 54° angle. Ideal for medium-pressure hydraulic and water applications (up to 5000 psi).

• Wire Spiral Hose: 4 or 6 layers of alternating spiral-wound steel wire. Superior for ultra-high pressure applications (up to 6000 psi) and heavy-duty impulse conditions.

• Textile Braid: Polyester or rayon yarn for low-pressure suction/discharge hoses.

Cover Layer

• Material: CR (chloroprene), SBR, or EPDM compounds

• Properties: Abrasion-resistant, ozone-proof, UV-stabilized

• Colors: Black (standard), blue, red, yellow, or custom (OEM ODM)

• Finish: Smooth, pin-pricked (for gas venting), or wrapped finish

Fittings & Hose Assembly Options

• Crimped fittings: Permanent attachment using hydraulic crimping machines. Provides 100% hose tensile strength.

• Reusable fittings: Screw-on design for field repairs. Ideal for mining and offshore applications.

• Adapters: NPT, JIC, ORFS, BSP, and flange connections

• Flanges: SAE split flange (Code 61/62) for large-bore hoses

• Protective sleeves & guards: Nylon, polyurethane, or PVC spiral guards for abrasion and cut protection

12. Certifications & Quality Standards

• ISO 9001:2015 (Quality Management)

• IATF 16949 (Automotive Quality)

• MSHA (Mine Safety & Health Administration) for underground mining

• ABS/DNV (Marine certification)

• FDA-compliant options for food/water contact

13. Key Advantages

• Long service life: 5-10 years in normal operating conditions

• Cost-effective: 30% lower total ownership cost vs. premium brands

• Versatile: One hose handles multiple water transfer tasks

• Safe: Exceeds burst pressure requirements with 4:1 design factor

14. Applications & Market Coverage

Industries Served:

• Agriculture & irrigation

• Construction & civil engineering

• Mining & quarrying

• Marine & offshore

• Municipal water treatment

• Industrial manufacturing

Global Presence: HENGHUA exports to over 70 countries including USA, Germany, Australia, Canada, Brazil, South Africa, UAE, and Russia. We serve as preferred supplier to engineering contractors, mining operators, and OEM equipment builders.

Custom Solutions: Provide pdf specification sheets, 3D drawings, and sample hoses for qualification. OEM ODM services include custom branding, packaging, and length marking.

Water Hose Product Line: Complete Classification

Wire Braided Water Hose

Definition: A rubber hose reinforced with one or two layers of high-tensile steel wire braid. Suitable for medium-pressure water transfer (1500-5000 psi) in construction, agriculture, and industrial equipment.

Key Specifications:

• Size: 1/4 inch to 2 inch ID

• Pressure: Up to 5000 psi (1-wire) or 6000 psi (2-wire)

• Bend radius: 15x OD minimum

• Standard: SAE 100R1, SAE 100R2, EN 853

Wire Spiral Water Hose

Definition: A heavy-duty rubber hose reinforced with four or six alternating spiral layers of steel wire. Designed for ultra-high pressure water jetting, mining dewatering, and hydraulic applications requiring extreme impulse life.

Key Specifications:

• Size: 3/8 inch to 2 inch ID

• Pressure: Up to 6000 psi (4-spiral) or 6000+ psi (6-spiral)

• Impulse life: 500,000+ cycles

• Standard: SAE 100R12, SAE 100R13, EN 856

High Pressure Hose (Thermoplastic)

Definition: A lightweight, non-rubber hose with thermoplastic inner tube and aramid fiber reinforcement. Ideal for high-pressure water cleaning, pressure washing, and robot welding coolant lines.

Key Specifications:

• Size: 1/4 inch to 1 inch ID

• Pressure: Up to 10,000 psi (burst)

• Temperature: -40°C to +100°C

• Standard: SAE 100R7, SAE 100R8

Suction & Discharge Water Hose

Definition: A large-bore, textile-reinforced rubber hose with a rigid helix wire to prevent kinking under vacuum. Used for pumping water from rivers, pits, and sumps.

Key Specifications:

• Size: 2 inch to 8 inch ID

• Vacuum rating: 27 inches Hg (full vacuum)

• Pressure: Up to 150 psi

• Cover: Wear-resistant SBR or EPDM

Potable Water Hose

Definition: A non-toxic, tasteless, and odorless rubber hose meeting FDA and NSF 61 standards for drinking water transfer.

Key Specifications:

• Material: White EPDM or NBR inner tube

• Certification: NSF 61, FDA 21 CFR 177.2600

• Temperature: -30°C to +80°C
