Steam Hose
About Steam Hose
A steam hose is a specialized rubber hose designed to convey saturated or superheated steam under high pressure and extreme temperatures. According to industry standards, a genuine steam hose must withstand continuous operating temperatures from -40°C to +210°C (-40°F to +410°F) while maintaining structural integrity and safety. Typical applications include steam cleaning, oil tank heating, construction curing, chemical plant maintenance, food processing, and rubber vulcanization lines.
Specifications for Steam Hose
| Parameter | Range |
|---|---|
| Inner Diameter (ID) | 3/8 inch to 4 inch (10mm to 102mm) |
| Working Pressure | Up to 300 psi (saturated steam) / 600 psi for high-pressure variants |
| Burst Pressure | 4x safety factor (minimum 1200 psi) |
| Temperature Range | -40°C to +210°C continuous |
| Safety Factor | 4:1 (static) or 10:1 (steam service recommended) |
Construction & Material Layering
Inner Tube: EPDM synthetic rubber or CR chloroprene rubber – provides exceptional heat, steam, and oxidation resistance. Smooth bore minimizes flow resistance and prevents scale accumulation.
Reinforcement Layer (Core Strength):
Wire Braided Hose (1 or 2 layers): High-tensile steel wire braid offers flexibility with moderate pressure capacity. Ideal for steam cleaning guns and mobile equipment.
Wire Spiral Hose (4 or 6 layers): Alternating spiral-wound high-carbon steel wires deliver superior burst resistance and impulse endurance. Best for stationary industrial steam lines with repetitive pressure spikes.
High Pressure Steam Hose: Combines spiral reinforcement with specially compounded heat-resistant rubber to handle both pressure and thermal cycling.
Cover: Pin-pricked EPDM or CR rubber cover – allows trapped gases to escape during steam service, preventing blistering. Resists abrasion, ozone, weather, and mild chemicals. Standard color: red or black.
Performance Features & Advantages
Pulse Performance: Exceeds 200,000 impulse cycles under dynamic steam pressure, verified by our in-house pulse test rig.
Media Resistance: Unaffected by steam, hot water, mild acids, alkalis, and ozone. Not for oil-based fluids.
Bend Radius: Minimum bend radius ranges from 5x ID (for braided) to 8x ID (for spiral). Flexible yet kink-resistant.
Durability: Cover passes 10,000+ cycles of abrasion resistance (DIN 53516). Excellent UV and weather aging.
Standards Compliance: Manufactured to EN 853, EN 856, SAE 100R1, SAE 100R2, and ISO 6134 (steam hose specific).
Standards & Certifications
Our steam hose carries:
ISO 6134 Type 1 & 2 (saturated steam up to +210°C)
SAE 100R6 / R7 (low-pressure steam applications)
BS 5342 (British standard for steam rubber hose)
China GB/T 3683 (national standard)
Certifications: ISO 9001:2015, MSHA (mine safety approval for underground use), SGS factory audit
We benchmark all performance metrics against Parker, Gates, and Eaton – ensuring our steam hose delivers comparable reliability at competitive price.
Application Scenarios & Industry Coverage
Construction: Concrete curing, asphalt heating, form cleaning
Marine: Boiler blow-down, tank cleaning, deck steam cleaning
Manufacturing: Rubber vulcanization, food equipment sanitation, textile mill humidification
Oil & Gas: Heavy oil heating, pipeline preheating
Chemical Plants: Reactor cleaning, heat tracing
HENGHUA exports steam hose solutions to over 70 countries, including USA, Germany, Russia, Brazil, South Africa, Australia, and UAE. We support OEM ODM customization – printing your logo, specific length (±1% tolerance), special cover colors, and custom packaging. Bulk discount available for container orders.
Complete Product Family Overview
We supply all steam hose sub-categories under one roof:
| Category | Definition | Key Specs | Best For |
|---|---|---|---|
| Saturated Steam Hose | For wet steam up to 210°C, pin-pricked cover | WP: 250 psi, 1/2″-2″ ID | Steam cleaning, curing |
| Superheated Steam Hose | For dry steam above 210°C, special EPDM tube | WP: 300 psi, up to 230°C | Power plant lines |
| High Pressure Steam Hose | Wire spiral reinforced for 600 psi steam | 4 or 6-spiral, 3/8″-1.5″ ID | Industrial process steam |
| Steam Hose Assembly | Pre-assembled with crimped fittings | Custom length + reusable fittings | Ready-to-install solutions |
| Low Pressure Steam Hose | Textile braided, lightweight | WP: 150 psi, -30°C to 170°C | Portable tools, vent lines |
Each type follows identical quality protocols: 100% tested for pressure, conductivity, and dimensional accuracy.
Factory Strength & Manufacturing Capability
Our Commitment to Your Success
As a leading China rubber hose producer and exporter, HENGHUA operates from a 35,000 m² modern campus strategically located near Ningbo port – reducing your logistics cost and lead time. Our 95 production lines include specialized units for wire braided hose, wire spiral hose, and high pressure hose. Daily capacity: 100,000 meters of finished hose, ensuring on-time delivery for bulk wholesale orders.
What Our Scale Means for You
Fast Turnaround: 20+ container loadings per day. Emergency orders shipped within 48 hours.
Consistent Quality: Every batch traced via unique ID card production system – from raw material to finished goods.
Flexible MOQ: 1 roll for sample testing; bulk discount for full container orders.
Cost Advantage: Vertical integration (mixing, braiding, curing, assembly) lowers your procurement cost by 15-20% versus trading houses.
Technology & Quality Control
R&D Investment: 7% of annual revenue into innovation; 18 active patents (utility models + inventions).
Lab Equipment: Pulse test bench (ISO 6803), burst tester (5000 psi), ozone aging chamber, spectrometer for material analysis.
Certifications: IATF 16949 (automotive grade), ISO 14001, and product-specific MSHA, DNV, CCS for marine steam hoses.
Human Resources & Expertise
Our 280 employees include 35 quality inspectors and 22 application engineers – many with 10+ years in steam hose formulation. We provide free technical support for hose assembly selection, fitting compatibility, and installation troubleshooting.
Product Quality & Standards Certification
Independent Verification: Our steam hose undergoes third-party SGS and BV audits annually. We publish downloadable pdf catalogues and specification sheets for each series.
Benchmark Performance: In comparative pulse tests, our spiral steam hose achieved 250,000 cycles vs. industry average of 150,000 – meeting or exceeding Gates Megasys and Parker 7314 series.
100% Factory Testing: Every hose length is hydrostatically tested to 1.5x working pressure. Random samples undergo destructive burst and adhesion tests. For hose assembly orders, each crimped fitting is verified with digital crimp records.
Selection and Usage Considerations
How to Choose the Right Steam Hose
Define steam type: Saturated (wet) or superheated (dry)? Use ISO 6134 Type 2 for superheated.
Measure max temperature: Never exceed 210°C continuous. For intermittent, allow cool-down cycles.
Check working pressure: Add 20% safety margin for pressure spikes.
Select end connections: Crimped fittings (permanent, leak-proof) vs. reusable fittings (field-replaceable). Common adapters include NPT, BSP, JIC, and flanges.
Consider protection: Add protective sleeves or guards for high-traffic areas to prevent abrasion and steam burns.
Installation & Safety Warnings
Never use general-purpose air/water hose for steam – catastrophic failure risk.
Avoid bending below minimum radius (see spec table).
Install with proper steam hose fittings rated for temperature and pressure.
Use slow warm-up (5-10 minutes) to prevent thermal shock.
Regularly inspect cover for blisters, cuts, or exposed wire.
Maintenance Checklist
Monthly: Visual check + gentle flex test.
Quarterly: Pressure test to 1.1x WP.
Annually: Replace if cover shows cracking or reinforcement corrosion.
About HENGHUA China Steam Hose Manufacturer
HENGHUA is a professional rubber hose factory with over 20 years of manufacturing experience, specializing in high-performance steam hose and industrial fluid conveyance solutions. Technically, we operate 95+ automated production lines, including advanced wire braiding and wire spiral machinery from Germany and Italy. Our in-house R&D team of 25 engineers ensures every steam hose meets or exceeds SAE, ISO, and EN standards. From service perspective, we provide end-to-end support—customized length, color branding, fitting assembly, and just-in-time delivery. Our global supply chain network enables rapid response to urgent bulk orders. Value-driven: we reduce your total ownership cost through durable design and minimized downtime. We invite you to partner with HENGHUA as your long-term steam hose supplier. Contact us today for a customized quote.
