Fuel Oil Hose Wrapped Surface 300 PSI
Model Series: FW300 (Fuel Oil Hose Wrapped Surface – Industrial Code)
A suction discharge hose engineered for demanding water transfer and dewatering applications. This 300 PSI suction discharge hose prevents collapse under full vacuum while maintaining flexibility for construction, agricultural, and industrial pumping systems. As a direct manufacturer and supplier in china, we provide a complete solution for engineers and procurement teams.
What Is a Suction Discharge Hose?
A suction discharge hose is a reinforced industrial rubber hose designed to both draw (suction) and transport (discharge) water, slurry, or non-corrosive fluids. Unlike a standard discharge hose (pressure only), a true suction hose includes a steel helix wire to prevent collapse under vacuum conditions. The FW300 series meets this definition, functioning as both a suction hose for water pump inlets and a high pressure hose for discharge lines up to 300 PSI.
What Is a Suction Discharge Hose Used For?
A suction discharge hose is used for transferring water, slurry, and non-corrosive fluids in construction, agriculture, and industrial pumping systems. It is commonly connected to water pumps for dewatering, irrigation, and general fluid transfer. This industrial suction hose is the standard choice for jobsites requiring both vacuum resistance and pressure capability.
Key Specifications at a Glance
- Working Pressure: 300 PSI
- Burst Pressure: 900 PSI (4:1 safety factor)
- Temperature Range: -30°C (-22°F) to +80°C (+176°F)
- Construction: NR/SBR tube + Multi-ply synthetic fiber + Helix steel wire + SBR cloth-impression cover
- Available IDs: 1/4″ to 2″ (6.4mm to 66mm)
- Standard Length: 100 meters per coil
How This 300 PSI Suction Discharge Hose Solves Common Failures
| Field Problem | How the FW300 Solves It |
|---|---|
| Hose collapse during suction | Embedded helix steel wire prevents crushing under full vacuum |
| Frequent hose replacement | 4:1 safety factor (900 PSI burst) + abrasion-resistant SBR cover extends service life |
| Poor performance in cold weather | NR/SBR tube remains flexible at -30°C (-22°F) |
| Kinking during operation | Hardwall structure with multi-ply fiber maintains roundness and flow |
| Cover cracking from sun/drag | Cloth-impression SBR cover resists ozone, UV, and mechanical abrasion |
Product Advantages
- No Collapse Under Vacuum: True vacuum resistant water hose design.
- True Dual Purpose: Handles both pump inlet suction and 300 PSI discharge.
- Abrasion & Weather Resistant Cover: Withstands concrete dragging and outdoor exposure.
- Cost-Effective Bulk Supply: Direct factory pricing with discounts for bulk and wholesale orders.
- OEM ODM Ready: Your brand, your packaging, your specification.
Technical Specifications Table
This suction discharge hose specification table helps engineers select the correct hose diameter for pump systems and water transfer applications.
| Part No. | ID (inch) | ID (mm) | OD (mm) | Working Pressure (PSI) | Burst Pressure (PSI) | Length (M) |
|---|---|---|---|---|---|---|
| FW300-04 | 1/4″ | 6.4 | 15 | 300 | 900 | 100 |
| FW300-06 | 3/8″ | 9.5 | 19 | 300 | 900 | 100 |
| FW300-08 | 1/2″ | 12.7 | 22 | 300 | 900 | 100 |
| FW300-10 | 5/8″ | 15.9 | 26 | 300 | 900 | 100 |
| FW300-12 | 3/4″ | 19.1 | 30 | 300 | 900 | 100 |
| FW300-16 | 1″ | 25.4 | 36 | 300 | 900 | 100 |
| FW300-20 | 1-1/4″ | 31.8 | 44 | 300 | 900 | 100 |
| FW300-24 | 1-1/2″ | 38.1 | 52 | 300 | 900 | 100 |
| FW300-32 | 2″ | 66 | 66 | 300 | 900 | 100 |
Download the complete pdf specification or request custom hose assembly lengths from our producer team.
Suction Discharge Hose vs. Standard Water Hose: Comparison
| Feature | FW300 Suction Discharge Hose | Standard PVC/Water Hose |
|---|---|---|
| Helix Wire | Yes (prevents collapse) | No |
| Vacuum Rating | Full vacuum resistant | Not rated (collapses) |
| Pressure Rating | 300 PSI | 150-200 PSI typical |
| Cold Flexibility | -30°C | 0°C (becomes stiff) |
| Abrasion Resistance | High (SBR cloth cover) | Low (smooth PVC) |
| Typical Application | Pump inlet + outlet | Gravity flow only |
Application Industries & Use Cases
This heavy duty suction discharge hose is specified by civil contractors, municipal teams, plant engineers, and agricultural operators.
- Construction: Dewatering excavations, slurry transfer, temporary bypass lines.
- Agriculture: Irrigation suction from ponds/lakes, liquid fertilizer transfer.
- Industrial: Cooling water lines, tank truck unloading, general water transfer.
- Municipal: Sewer bypass, stormwater pumping, street cleaning.
Real Use Case Sentence:
This flexible suction discharge hose is commonly used as a suction hose for water pumps on construction sites and as a dewatering hose in mining and municipal flood control projects.
Hose Assembly & Fittings Integration
To create a complete hose assembly, match this rubber suction hose with:
- Crimped fittings: Permanent, zero-leak connections.
- Reusable fittings: Field-attachable for repairs.
- Adapters & flanges: Convert to NPT, BSP, or camlock.
- Protective sleeves & guards: Extend life in high-traffic areas.
We provide custom Assembly services – cutting, skiving, crimping, and 100% pressure testing before shipment. Request our pdf fitting selection guide.
Technical Standards & Quality Assurance
- Standard: Manufactured to internal Q/LF 001, meeting hardwall suction/discharge requirements.
- Safety Factor: 4:1 (burst to working pressure).
- Testing: 100% factory static pressure test at 1.5x working pressure + batch vacuum resistance validation.
- Traceability: Batch numbers for full material traceability.
- Certification: ISO 9001:2015 factory.
Real Customer Result:
*A construction contractor in Southeast Asia replaced standard PVC hose with this suction discharge hose for dewatering and reduced hose collapse failures by over 70% across a 12-month project.*
Trust Commitment:
Each batch is tested for vacuum resistance and burst pressure before shipment. We stand behind every meter.
Installation, Operation & Maintenance
- Bend Radius: Minimum = 8 x hose OD. Tighter bends will kink the helix wire.
- Fitting Attachment: Use only recommended crimped fittings or reusable fittings designed for helix-reinforced wire braided hose.
- Vacuum Service: Rated for full vacuum. Ensure fitting IDs do not create restriction.
- Fluid Compatibility: Designed for water and non-corrosive fluids. For diesel or oils, consult our support team.
- Storage: Away from ozone, direct sunlight, and heat sources.
Frequently Asked Questions (FAQ)
Q: What is a suction discharge hose used for?
A: A suction discharge hose is used for transferring water, slurry, and non-corrosive fluids in construction, agriculture, and industrial pumping systems. It is commonly connected to water pumps for dewatering, irrigation, and fluid transfer.
Q: Can this suction discharge hose be used for fuel or oil?
A: No. Despite the industrial code “Fuel Oil Hose,” the FW300 series is engineered specifically for water and non-corrosive fluids. Request our dedicated fuel hose series for petroleum products.
Q: What is the difference between a suction hose and a discharge hose?
A: A suction hose contains a helix steel wire to prevent collapse under vacuum. A standard discharge hose has no wire and will collapse on pump inlets. The FW300 handles both roles.
Q: How do I choose the correct suction hose diameter?
A: Match the hose ID to your pump port size. For a 2″ pump port, use FW300-32 (2″ ID). Undersizing causes cavitation.
Q: Do you offer bulk pricing for wholesalers and distributors?
A: Yes. As a direct factory, wholesaler, and exporter, we provide tiered price lists for bulk and wholesale orders. Contact us for discount schedules.
Q: Can you provide pre-assembled hoses with crimped fittings?
A: Yes. We offer complete hose assembly with crimped fittings, reusable fittings, adapters, and flanges. Send your specification for a quote.
How to Choose the Right Suction Discharge Hose
- Diameter: Match your pump or equipment port size (1/4″ to 2″ available).
- Pressure: Confirm system pressure ≤ 300 PSI.
- Vacuum: Does the hose see pump inlet vacuum? → Requires helix wire (FW300 has it).
- Environment: Outdoor/abrasive conditions? → SBR cloth-impression cover (standard).
- Length: Standard 100M coils or custom hose assembly lengths.
HENGHUA: Your Industrial Rubber Hose Solution Source
HENGHUA is a trusted rubber hose manufacturer, distributor, and exporter from china with over 15 years of experience. Our factory controls every production step – from raw material compounding to final pressure testing – ensuring consistent quality across wire braided hose, wire spiral hose, and high pressure hose products.
Why HENGHUA is the Right Source:
- Complete Solutions: Hoses plus full hose assembly with crimped fittings, reusable fittings, adapters, flanges, protective sleeves, and guards.
- OEM ODM Capability: Your brand, your packaging, your specification.
- Global Export Experience: 60+ countries supplied.
- Transparent Wholesale Pricing: Direct supplier access with bulk discounts.
When you need a dependable source for industrial suction hose that reduces downtime and total cost of ownership, HENGHUA is your producer.
